Red Winch Snatch Ring 5T + Roadsafe Soft Shackle

Save $6.00
Red WinchSKU: RWSRING5T+SB039

Price:
Sale price$96.00 Regular price$102.00

Description

Red Winch Snatch Ring 5T + Roadsafe Soft Shackle & Drying Bag

---------------------------------------------------

Our RED Winch “Snatch Rings” offer a strong, lightweight and safe alternative to the traditional metal snatch block.

The “Snatch Ring” fits perfectly into a pocket or glove box. This makes it an ideal accessory to have in your truck for overlanding expeditions or in competition when your co-driver is having to climb steep slopes.

Frictional losses are not as big as one might think, especially when using low friction line such as Dyneema or Plasma.

Lighter and smaller than a conventional steel or aluminium pulley block, these Snatch Rings are a popular alternative for many applications where traditional blocks once ruled. Instead of rolling on a pulley sheave, the active line with a ferrule merely slides on the inside smooth surface of the ring.

Because it weighs very little, it is less likely to cause injury if it strikes a crew member in the unlikely event the truck rolls and it hasn’t been secured.

It is easy to store in your truck cab, doesn’t damage surrounding kit, doesn’t rust and can be used for in far more situations that a traditional steel shackle.

Our Redwinch “Snatch Rings” have been extensively tested. The ideal strength can approach five (5) times the line strength if required. This means when attached to a typical winch line, it is likely the winch line will break long before the “Snatch Ring” does.

  • Outer Dia: 80mm,
  • Inner Diameter: 28mm
  • Rope Running Diameter: 6-11
  • Soft Shackle Rope Diameter: 12-14mm

This “Snatch Ring” is published and rated / certified to the figures above.

Warning:

This product is not to be used with steel D-Shackles or Bow Shackles. Only Soft Shackles should be used

Durability

Tough, practical, quick and safe. These rings have worked well in the field.

In competition use, for the amount of times you actually need one, we feel it is a much more practical accessory to have in your truck than the heavy traditional snatch blocks.

Our testing has show that using the larger diameter Soft Shackle works best with recovery situations. Giving much bigger factors of safety in the line and a more practical feel to them. The larger rope spreads the loads much more efectively and produces very little friction or heat during the recovery process.

Our recommendation is to use 9mm soft shackle with this “Snatch Ring”

------------------------------------

Roadsafe  Soft Shackles are designed to be a safe, light weight, easy to use alternative to conventional steel bow shackles.

Made from UHWMPE 10mm 12 strand synthetic rope, as used in a range of winch ropes supplied by Roadsafe, the Roadsafe soft shackles are supplied complete with high visibility abrasion resistant sheaths, and pre-tensioned for immediate use.

By using a Roadsafe soft shackle you effectively remove a very heavy and potentially lethal standard steel shackle from your recovery system.

Being manufactured from rope the Roadsafe soft shackle floats, so no more lost shackles in muddy, watery environments during recovery, and is flexible, so suitable for a huge variety of applications.

 Rope Spliced Breaking Strain 10mm – 9000kgs

A few key features of the Roadsafe Soft Shackle…

 ·         Maximum strength to weight ratio and strength comparable to steel

·         Lowest elongation, minimal stretch

·         Light weight for gross weight reduction

·         Time saver, takes less time to set up than a conventional shackle

·         Floats in water & muddy environments

·         Abrasion resistant sleeves for maximum durability

In competition use, for the amount of times you actually need one, we feel it is a much more practical accessory to have in your truck than the heavy traditional snatch blocks.

Our testing has show that using the larger diameter Soft Shackle works best with recovery situations. Giving much bigger factors of safety in the line and a more practical feel to them. The larger rope spreads the loads much more efectively and produces very little friction or heat during the recovery process.

Our recommendation is to use 14mm soft shackle with this “Snatch Ring”

Video

16mm Soft Shackle in use with our larger “Snatch Ring” on a double and triple line pull
